Components and characteristics of mobile concrete mixing sta

The whole equipment of the mobile concrete mixing station is compact, and all the working procedures of concrete production are concentrated in a towing unit to understand the components and characteristics of the mobile mixing plant.

The components of mobile concrete mixing station:

1. Mixing machine: Adopt the current mainstream mixer-JS double horizontal shaft forced concrete mixer, it can mix a variety of concrete, such as fluidity, semi-dry hardness and dry hardness.

2. Material weighing system: mainly divided into aggregate weighing, powder weighing and liquid weighing three parts, the production of different specifications of concrete mainly depends on weighing system.

3. material handling system: transportation of aggregate, powder and liquid additives.

4. Material storage system: the storage mode of mixing with HZS concrete is basically the same, aggregate is piled in open air; powder is stored in closed steel structure cement bin; additive is stored in steel structure container.

5. Control system: The control system can be based on different user requirements and the size of the mixing station, but has different functions and configuration, in general, the control system of the mobile mixing station is simpler than the large stationary concrete batching plant.

characteristics of mobile concrete mixing station:

Quick disassembly and installation, easy to move: Except for external equipment such as screw conveyor, cement bin, all the wiring of the concrete batching plant need not be removed, only 30 tons of crane with, one day can be dismantled displacement. Installation, such as smooth and solid ground, do not need the foundation, can be in place on the same day production, tight requirements for the project unit is very suitable.

The mobile batching plant is equipped with tires and traction pins to allow maximum speed up to 60 km / h when towing vehicles are towed. The total weight of the mixing station is 23.5 tons. When the station is moved, all the accessories will be removed at once with the station.
