The common type of single horizontal shaft concrete mixer

The single horizontal axis concrete mixer is relative to the double shaft horizontal concrete mixer. The common models are JDC350 and JDC500 concrete mixer. The following is the detailed information of the single horizontal axis concrete mixer equipment, including parameters, composition, structure and performance characteristics.

Detailed parameters of single horizontal shaft concrete mixer (JDC350 concrete mixer, JDC500 concrete mixer):
Mixer type: strong mixer.
Application: Engineering Construction
Power type: Electric
Layout: Horizontal
Mixing mode: forced mixing.
Operation mode: continuous operation mode.
Installation mode: mobile type
Discharge capacity: 350L/500L
Motor power: 15KW/18.5KW
Production capacity: 17.5m /h 25-30m /h
Brief introduction of single horizontal shaft concrete mixer structure
Feeding system (feeding rack, feeding funnel, hoist ditch), mixing system (mixing drum, mixing shaft, mixing blade), transmission mechanism, water supply system, unloading mechanism, frame (base, leg, walking tire), electrical control system and other components
The performance characteristics of single horizontal shaft concrete mixer are as follows:
Compact structure, reasonable design, simple operation, low energy consumption, low noise, reliable quality, stable operation, high mixing efficiency and good quality of concrete production
